The RB1450 HD Two Section Pedestal Boom from Atlas Copco

Atlas Copco offers a two section pedestal boom called RB1250 XD, which is specifically designed for heavy duty gyratory crusher applications. The equipment has a horizontal reach of approximately 12.5 m and includes the AutoLube automatic boom lubrication system and the SlewDevice with 270 degree rotation.

Key Features

The product features of the RB1450 HD pedestal boom are:

  • HB2000 or MB1700 breaker offers improved productivity
  • AutoLube automatic boom lubrication system increases boom’s life expectancy and reduces maintenance
  • SlewDevice with 270 degree rotation provides optimum reach and ease of maintenance

Specifications

The specifications of the RB1450 HD pedestal boom are provided in the table below:

Duty Heavy
Application Gyratory crusher
Horizontal reach (breaker vertical), max 14.2 m
Vertical reach (excluding breaker), max 9 m
Swing 270
Number of boom sections 2
Power pack 110 kW
Radial raking depending on reach, max at 2 m 1100 - 5500 kg
Axial raking 2200 kg
Operating mass excluding breaker, Power pack and control console 24400 kg
Recommended breaker weight 1700 - 2000 kg
Hydraulic breaker
MB1700, HB2000
